SPECIFICATION

1,Working Medium:Air source

2,Body material:Aluminum die-casting

3,Filter bowl and Lubricator bowl material:PC

4,Filter element material:Brass

5,Bowl Guard:Reinforce plastic

6,Seal Material:NBR

7,Adjustabing knob:POM

8,Working pressure:1~10Bar

9,Working Temperature:-10~60℃

10,Filtration fineness:40µ,5µ,20µ can be available

11,Mounting type: Pipe mounting or bracket support mounting

12,Regulator type:Diaphragm type

13,Lubricator type:Oil volume adjustable during working

14,Port size:G1/8”,G1/4”,G3/8”,G1/2”

15,Drainage model:Manual drainer,automatic drainer

16,Filter bowl oil bowl pressure resistance:1.6Mpa

17,Flow direction:Left to right standard,Right to left direction by requirement

18,Body Width:40mm,60mm

19,Design type:Modular Design
